Ping

Ping, with HTTP instead of ICMP, and a graph. pepe ping sends one request every second to each target and draws its latency over time, with each ping split into where its time went: the DNS lookup, the TCP connect, the TLS handshake, the wait for the first byte and the download. It is what to leave open in a corner of the screen while something is deployed, and the on-ramp to a load test: the same -H, -m, -d, -k, -p and -t apply.

pepe ping https://example.com                       # a request a second, forever; q leaves the summary
pepe ping api.example.com cdn.example.com --name api,cdn   # several, each a line on the graph
pepe ping https://example.com --every 200ms --window 5m    # faster, with five minutes on screen
pepe ping https://api.example.com/health --slo total=300,ttfb=100 --bell   # limits; exit 4 if broken
pepe ping example.com --all-ips -4                  # every IPv4 address it resolves to, each its own line
pepe ping db.internal --tcp --port 5432             # only connect: a TCP ping of the port
pepe ping 10.0.0.0/29:8080                          # every host of a range
pepe ping --cmd 'dig example.com' 'curl -s https://example.com'   # commands, timed
pepe ping aws:eu-west-1 aws:us-east-1               # cloud regions, by shorthand
pepe ping https://example.com --jsonl > pings.jsonl # no screen: one JSON object per ping
pepe ping https://example.com --csv -n 100          # one CSV line per ping, a hundred of them
pepe ping https://example.com --json -n 10          # the summary as JSON
pepe ping https://example.com --once                # three quick pings, then why it is slow, and out

Targets

A host without a scheme is https://, unless it has a port or is this machine (localhost, 127.0.0.1, ::1), where it is http://. A target can be:

• a URL, or a host, or host:port;
• aws:REGION, a cloud region by shorthand (ec2.REGION.amazonaws.com);
• an IPv4 range, 10.0.0.0/29 or 10.0.0.0/29:8080, every host of it a target (up to a /24);
• with --all-ips, every address a name resolves to, each a target of its own, named host IP;
• with --tcp, a port: the ping is the connection, nothing is sent; --port is the port for a target that names none (80), and --tcp-rst fail makes a refused connection a failure rather than the answer it is by default (something is there to refuse);
• with --cmd, a command: run in the shell every interval and timed, its exit code the status.

--name api,cdn names the targets in order, --color red,#8cb8ff colours their lines, -4 and -6 pick the address family, and --interface en0 (or an address) sends from that interface. At most 256 targets.

HTTP/2

A ping takes HTTP/2 when the server offers it through ALPN, which most do over TLS, and says so: HTTP/2 200 in the once line and the pings list, "http_version": "HTTP/2" in the report, h2 under the TLS details. The phases are the same, the first byte being the response's headers. --http1 stays on HTTP/1.1, to compare the two. A server that offers only HTTP/1.1 is noted among the findings. The load-testing modes still speak HTTP/1.1, where pepe's engine is fastest.

Each phase, every ping

Each ping opens its own connection, so every phase is measured every time, and the TLS session is still resumed when the server allows it: the first handshake is full, the next ones resumed, and the report says how long each kind takes. --keep-alive keeps the connection instead, as a browser would, and the pings after the first measure only the server (dns, connect and tls are then kept). Redirects are followed (unless --disable-redirects), each hop listed with its status and time, and the phases of the whole chain added up. Through a proxy (-p), the connection is the proxy's and only the first byte and the download are measured.

The screen

The table above the views has each target's last, min, avg, max, jitter (the mean difference between one ping and the next), p95, p99, loss and timeouts over what the graph shows, or over the whole run with t.

Keys

What to look at

The numbers come with what they mean, in the summary, in the phases view and under findings in the JSON, most serious first: nothing answered, and why; pings lost and timed out; 5xx; 401, 403, 404 or 429 on every ping; every request redirected, with the final URL to point at and what the chain costs; a slow DNS lookup; connecting as a share of the request, read as a round trip; the TLS session never resumed, so every connection pays the full handshake, or resumed and how much it saves; the server closing every connection; the server's own share of the time, with its Server-Timing when it sends one; a large or slow download; a text body that isn't compressed though gzip and br were offered; a cache answering, so the server itself wasn't measured; HTTP/1.0; a certificate expired or expiring within 30 days; and a long tail.

pepe ping URL --once is the quick version: three pings 200 ms apart, the last one's phases, what answered, the findings, and out.

pepe ping · https://example.com/ · 3 pings
  dns 1.84ms → connect 49.88ms → tls 66.57ms → first byte 63.72ms → download 33µs · 182.5ms in all
  HTTP/1.1 200 · text/html · 334 B · 104.20.23.154:443 from 192.168.0.164 · TLS 1.3 TLS13_AES_256_GCM_SHA384
  certificate for example.com by SSL Corporation, expires in 76 days
  ▲ TLS sessions are resumed: 66.82ms after the first handshake's 118.6ms, still 66.82ms of 190.0ms
  · answered by a cache (cf-cache-status: HIT): the server itself wasn't measured

Limits

--slo total=500,ttfb=200,connect=100,dns=50,tls=150,download=100, in milliseconds, marks a ping that goes over any of them, counts them in the report, and makes the exit code 4. The exit code is 1 when nothing ever answered. --bell rings the terminal on a failed or slow ping. (A load run's limits are --fail-if; a ping refuses it and points here.)

Flags

-n and -z end the run; without them it runs until q. -t is the timeout, -H, -m, -d, -u, -p, -k, --disable-compression and --disable-redirects shape the request, and --metrics serves the live numbers (Output).

Without a screen

Piped, or with --jsonl, --csv or --json, there is no screen: a line per ping as it happens, as text, JSON or CSV, then the summary on stderr, or the JSON report on stdout. pepe schema ping prints the report's schema, and the shape of a --jsonl line is under its sample definition. Two ping reports can be held against each other with pepe compare, phase by phase (Compare).

pepe ping https://example.com --jsonl -z 5m > pings.jsonl
pepe ping https://example.com --json -n 10 --save before.json
