Flows: a sequence of requests

pepe flow: a chain of three steps, each a row on the dashboard

pepe flow runs a chain of requests where a value from one response feeds the next: log in, take the token, use it. Each unit of concurrency is one user walking the steps in order with its own values, over and over; each step is a row on the dashboard, as endpoints are in API mode, with its own throughput, latency and statuses.

bash

pepe flow checkout.toml -c 20 -z 1m
pepe flow checkout.toml -n 500 --json > checkout.json

The flow file

toml

# checkout.toml
name = "checkout"

[vars]
host = "https://shop.example.com"

[[step]]
name = "login"
method = "POST"
url = "{{host}}/login"
headers = ["Content-Type: application/json"]
body = '{"user": "demo", "password": "demo"}'
capture = { token = "json:$.token", session = "header:Set-Cookie" }

[[step]]
name = "cart"
url = "{{host}}/cart"
headers = ["Authorization: Bearer {{token}}"]
capture = { cart = "json:$.items[0].id" }

[[step]]
name = "checkout"
method = "POST"
url = "{{host}}/cart/{{cart}}/checkout"
headers = ["Authorization: Bearer {{token}}"]
expect = 201

Key	What it is
`name`	The flow's name (the file's name without its extension when left out)
`[vars]`	Values every chain starts with, for `{{holes}}`
`[[step]].name`	The step's name on the dashboard (`step 1`, `step 2`, … when left out)
`method`, `url`, `headers`, `body`	The request; `url` is required, `method` is GET by default, `headers` are `Name: value` lines, and each can have `{{holes}}`
`expect`	The status the step must get; without it, any 2xx passes
`capture`	Variables to take from the response, each `name = "spec"`

Holes and captures

{{name}} holes are filled from [vars] and from earlier steps' captures; a hole nothing fills is an error when the file is read, naming the step and the variable. A capture is one of:

Spec	Takes
`json:$.path.to[0].value`	A value in a JSON body, by path: fields, and `[n]` indexes; `$.` is optional
`header:Name`	A response header's value
`regex:pattern`	The first group of a regular expression over the body (the whole match without a group)
`body`	The whole body, trimmed

A step passes when it gets a 2xx, or the status expect names; a step that fails, or whose capture finds nothing, ends the chain with that said in the failure causes, and the user starts over. Up to a megabyte of each response is kept for its captures.

Running it

-n counts chains, not requests; -c, -z, -H (sent with every step), -t, --rate (which paces every request, steps included), --warmup and the other options work as usual. There is no setup screen for a flow: edit the file and r runs it again. --json prints the usual report plus flow: its name, how many chains started and completed, and steps, one entry per step with requests, failures, throughput, median, p99 and status codes. Piped, the dashboard's verdict is printed. --metrics serves a row per step.
